Titre : D-558-2 cockpit instrument panel
Description : (La description de cette image n'existe qu'en anglais)
This 1949 photograph of the D-558-2 cockpit instrumentation panel illustrates the complex array of dials and switches that confronted the research pilot. The instruments included a Mach meter; altimeter; fuel, oil, and oxygen pressure gages; a landing gear indicator; a gage showing the movable horizontal stabilizer's position; and warning lights for the generator and hydraulic pressure.
|
|
